Fogra
大多数特征文件有两种变体。以FOGRA v3开头的文件表示三行颜色条，其他文件表示两行颜色条。
Offset Printing 胶印
ISOnewspaper26v4 (IFRA26L).txt666
Newspaper coldset offset printing according to ISO 12647-3:2004, standard newsprint, screen ruling 40 l/cm ± 2 l/cm
ISOcoated (FOGRA27).txt FOGRA v3 ISOcoated (FOGRA27).txt
Commercial offset printing, paper type 1 or 2, i.e. gloss or matt coated, 115 g/m2, positive-acting plates, periodic screen 60/cm, solids and TVI according to ISO 12647-2:2004
ISOwebcoated (FOGRA28).txt FOGRA v3 ISOwebcoated (FOGRA28).txt
Commercial offset printing, paper type 3, i.e. glossy coated web, 60 g/m2, positive-acting plates, periodic screen 60/cm, solids and TVI according to ISO 12647-2:2004
ISOuncoated (FOGRA29).txt FOGRA v3 ISOuncoated (FOGRA29).txt
Commercial offset printing, paper type 4, i.e. uncoated white offset, 120 g/m2, positive-acting plates, periodic screen 60/cm, solids and TVI according to ISO 12647-2:2004
ISOuncoated_yw (FOGRA30).txt FOGRA v3 ISOuncoated_yw (FOGRA30).txt
Commercial offset printing, paper type 5, i.e. uncoated slightly yellowish offset, 120 g/m2, positive-acting plates, periodic screen 60/cm, solids and TVI according to ISO 12647-2:2004
ISOcofcoated (FOGRA31).txt FOGRA v3 ISOcofcoated (FOGRA31).txt
Continuous forms printing, paper type 2, i.e. matt coated offset, 115 g/m2, positive-acting plates, periodic screen 60/cm, solids and TVI according to ISO 12647-2:2004
ISOcofuncoated (FOGRA32).txt FOGRA v3 ISOcofuncoated (FOGRA32).txt
Continuous forms printing, paper type 4, i.e. white uncoated offset, 80 g/m2, positive-acting plates, periodic screen 60/cm, solids and TVI according to ISO 12647-2:2004
ISOcoated v2 eci (FOGRA39).txt FOGRA v3 ISOcoated v2 eci (FOGRA39).txt
Commercial offset printing, paper type 1 or 2, i.e. gloss or matt coated, 115 g/m2, positive-acting plates, periodic screen 60/cm, solids and TVI according to ISO 12647-2:2004/Amd 1
SC paper eci (FOGRA40).txt FOGRA v3 SC paper eci (FOGRA40).txt
Commercial offset printing, SC paper, i.e. glossy coated web, 60 g/m2, positive-acting plates, periodic screen 60/cm, solids and TVI according to ISO 12647-2:2004
FOGRA v3 PSO_MFC (FOGRA41).txt
Heat-set web offset printing, MFC paper
FOGRA v3 PSO_SNP (FOGRA42).txt
Heat-set web offset printing, standard newsprint paper
FOGRA v3 PSO_Coated_NP (FOGRA43).txt
Commercial offset printing, paper type 1 or 2, i.e. gloss or matt coated paper, non-periodic screening
FOGRA v3 PSO_Uncoated_NP (FOGRA44).txt
Commercial offset printing, paper type 4, i.e. uncoated white paper, non-periodic screening
FOGRA v3 PSO_LWC_improved (FOGRA45).txt
Heatset web offset printing on improved LWC paper (paper type 3), characterization data FOGRA45L
FOGRA v3 PSO_LWC_standard (FOGRA46).txt
Heatset web offset printing on standard LWC paper (paper type 3), characterization data FOGRA46L
FOGRA v3 PSO_uncoated (FOGRA47).txt
Offset printing on uncoated white paper (paper type 4), characterization data FOGRA47L
FOGRA v3 PSO_INP_Paper (FOGRA48).txt
Commercial offset printing according to ISO 12647-2:2004, paper type INP (improved newsprint), 49 g/m2, positive-acting plates, tone value increase curves C (CMY) and D (K), white backing.
FOGRA v3 PSO_Coated_v2_300_Matte_laminate (FOGRA49).txt
Commercial offset printing according to ISO 12647-2:2004, paper type 1 and 2, gloss or matt coated paper, 115 g/m2, positive-acting plates, AM screen with 150–200 lpi, tone value increase curves A (CMY) and B (K), after lamination with matte OPP film (15 µm), white backing.
FOGRA v3 PSO_Coated_v2_300_Glossy_laminate (FOGRA50).txt
Commercial offset printing according to ISO 12647-2:2004, paper type 1 and 2, gloss or matt coated paper, 115 g/m2, positive-acting plates, AM screen with 150–200 lpi, tone value increase curves A (CMY) and B (K), after lamination with glossy OPP film (12–15 µm), white backing.
FOGRA v3 PSOcoated v3 (FOGRA51).txt
ISO 12647-2:2013 based offset printing conditions for premium coated paper (FOGRA 51) with a moderate amount of optical brightening agents (print substrate 1), 115 g/m2, tone value increase curves A (CMYK)
Gravure Printing 凹印
FOGRA v3 ECI_PSR_LWC_PLUS_V2.txt
Web-fed gravure, paper type LWC Plus (improved LWC paper) gloss coated, 70 g/m2, according to ISO 12647-4
FOGRA v3 ECI_PSR_LWC_STD_V2.txt
Web-fed gravure, paper type LWC (light-weight coated), 51 g/m2, -according to ISO 12647-4
FOGRA v3 ECI_PSR_SC_STD_V2.txt
Web-fed gravure, paper type SC (super calendered), 56 g/m2, according to ISO 12647-4
FOGRA v3 ECI_PSR_SC_PLUS_V2.txt
Web-fed gravure, paper type SC Plus (whiter super calendered), 52 g/m2, according to ISO 12647-4
PSRgravureHWC.txt FOGRA v3 PSRgravureHWC.txt
Gravure printing, paper type HWC, 70 g/m2, according to PSR of ECI, target values from PSRgravureHWC_ECI2002.txt
PSRgravureLWC_sb.txt FOGRA v3 PSRgravureLWC_sb.txt
Gravure printing, paper type LWC, according to PSR of ECI, target values from PSRgravureLWC_ECI2002.txt
PSRgravureMF_sb.txt FOGRA v3 PSRgravureMF_sb.txt
Publication gravure, machine finished paper, according to process standard gravure of ECI
PSRgravureSC_sb.txt FOGRA v3 PSRgravureSC_sb.txt
Gravure printing, paper grade SC, according to PSR of ECI, target values from PSRgravureSC_IS12642.txt
Screen Printing 丝网印刷
SilkScreenPrint (FOGRA9).txt
Screen printing, gamut class 2, similar to offset paper grade 1, according to ISO 12647-5
ICC Profiles
eciCMYK.icc
CMYK-based color exchange space known as FOGRA53, see also Fogra website
PSOsc-b_paper_v3_FOGRA54.icc
Heat-set web offset printing in accordance with ISO 12647-2:2013 on SC-B paper (super calendered)
PSR_LWC_PLUS_V2_M1.icc
Web-fed gravure printing in accordance with ISO 12647-4:2014, paper type LWC Plus gloss coated, measured over self backing.
WAN-IFRAnewspaper26 v5.icc
Generic newspaper profile from WAN-Ifra for printing conditions with 26% TVI, 220% max. ink coverage, maximum GCR, primary and secondary colors of ISO 12647-3:2013
IDEAlliance
特征文件来自美国非营利性组织：International Digital Enterprise Alliance
GRACoL2013_CRPC6.icc
GRACoL digital printing profile (ISO 15339-2), created using CGATS21-2-CRPC6.txt color characterization data Separation details: TAC: 320%, GCR: Medium+, Max black: 100%, TVI: CMY 16% K 19.1%
GRACoL2013UNC_CRPC3.icc
GRACoL digital printing profile (ISO 15339-2), created using CGATS21-2-CRPC3.txt color characterization data Separation details: TAC: 280%, GCR: Medium+, Max black: 100%, TVI: C19% M19.1% Y19% K22.1%
GRACoLCoated1_ISO12647-7_ControlStrip2009.txt
Sheet-fed commercial offset printing, paper grade 1, coated, ISO 12647-7
IDEAlliance ISO 12647-7 Control Wedge 2013 GRACoL2006 Coated1 Ref.txt
Printing conditions based on reference characterization data GRACoL2006 Coated1, for ISO 12647-7 compliant validation measurements using the 3-row IDEAlliance color bar
IDEAlliance ISO 12647-7 Control Wedge 2013 SWOP2006 Coated3 Ref.txt
Printing conditions based on reference characterization data SWOP2006 Coated3, for ISO 12647-7 compliant validation measurements using the 3-row IDEAlliance color bar
IDEAlliance ISO 12647-7 Control Wedge 2013 SWOP2006 Coated5 Ref.txt
Printing conditions based on reference characterization data SWOP2006 Coated5, for ISO 12647-7 compliant validation measurements using the 3-row IDEAlliance color bar
SWOPCoated3_ISO12647-7_ControlStrip2009.txt
Web offset publication printing, paper grade 3, coated, ISO 12647-7
SWOPCoated5_ISO12647-7_ControlStrip2009.txt
Web offset publication printing, paper grade 5, coated, ISO 12647-7
下载测控条文件：
IDEAlliance-ISO-12647-7-2013-控制梯尺：-i1Pro.tif
Ugra_FograMediaWedge-CMYK-V3-AED.tif
